Installation and troubleshooting methods of agriculture sprayers

Views:329     Author:Site Editor     Publish Time: 2021-09-29      Origin:Site

Installation and troubleshooting methods of agriculture sprayers


The agriculture sprayer has the advantages of super hardness, economy, and durability. Therefore, more and more people choose to use agriculture sprayers. Next, let us learn about the installation and troubleshooting methods of agriculture sprayers. Here are some answers.


Here is the content list:

  • Installation steps.

  • Common faults and troubleshooting methods.


Installation steps.

To install the agriculture sprayer, first take out the hose, switch, spray rod, spray head, hand crank, connecting rod, spray rod holder, and other accessories. Second, connect one end of the hose to the water outlet and tighten it, and connect the other end to the switch and tighten it at the bottom. Third, put a rubber pad on the top of the switch to prevent water leakage, and tighten the spray rod. Fourth, put a rubber pad on the other end of the spray rod, connect the spray head and tighten it. Fifth, connect the connecting rod and spray rod fixing clip with the agriculture sprayer, and then insert the hand crank into the hole under the sprayer. Finally, connect the connecting rod with the hand crank to complete the installation.


Common faults and troubleshooting methods.

When agriculture sprayers are used, they will more or less malfunction. The following are several common faults and troubleshooting methods. The first situation is insufficient spray pressure and poor atomization. If the water ball valve of the agriculture sprayer is set up by dirt, the water inlet valve can be removed and the dirt can be removed with a cloth. If the leather bowl is damaged, it can be replaced with a new one. If the connection part is not equipped with a sealing ring, or the sealing ring is damaged and the air is leaking, the sealing ring can be installed or replaced.


The second situation is that the spray does not become foggy. If the oblique hole of the nozzle body of the agriculture sprayer is blocked by dirt, the oblique hole can be dredged. If the nozzle is blocked, the nozzle can be disassembled and cleaned. However, hard objects such as iron wire or copper needles should not be used to poke the nozzle to prevent the hole from expanding and degrading the spray quality.


The third situation is that the switch is leaking or cannot be turned. If the switch cap of the agriculture sprayer is not tightened, the switch cap should be tightened. If the gasket on the switch core is worn, replace the gasket. If the switch cannot be turned, the reason is that it has been stored for a long time or used for a long time, and the switch core is stuck due to the corrosion of the agent. The parts should be removed and cleaned in kerosene or diesel. When it is difficult to remove it, soak it in kerosene for some time, and then remove it after disassembly. Do not hit with hard objects.


The fourth case is water leakage at each connection. If the connector of the agriculture sprayer is loose, the nut should be tightened. If the washer is not leveled or damaged, the washer should be leveled, or the washer should be replaced. If the gasket is hardened due to dry shrinkage, it can be used after being soaked in animal oil.


Our official website is www.gfsprayer.com. If you are interested in our agriculture sprayer products, please contact us. We believe that our products will be recognized by you.
